Sunday, September 21, 2025

Xtool D9S vs D9S Pro vs D9 Max Comparison

 What’s the difference among Xtool D9S, D9S Pro and D9 Max professional diagnostic scanners?

Check the table comparison below:

D SeriesXtool D9SXtool D9S ProXtool D9 Max
Imagextool d9sxtool d9s proxtool d9 max
Operating systemAndroid 10Android 10Android 10
ProcessorQuad-core 1.5GHzQuad-core 1.5GHzQuad-core 1.5GHz
Memory4G+ 128G4G+ 128G4G+ 128G
Screen size9.7 inch9.7 inch9.7 inch
Battery Capacity6400mAh 7.2V6400mAh 7.2V6400mAh 7.2V
Connection methodWiFi, USBWiFi, USBWiFi, USB
Charging methodType CType CType C
Free update3 Years Free Update3 Years Free Update3 Years Free Updae
Renewal after free update258USD/Year358USD/Year
Full system diagnosticsYesYesYes
Complete OBDII functionYesYesYes
AutoScanYesYesYes
Read ECU info.YesYesYes
Read/Clear DTCYesYesYes
Live DataYesYesYes
Read Freeze FrameYesYes
Active Test (Bidirectional control)YesYesYes
Special functions42+42+42+
IMMO ResetYesYesYes
ECU CodingYesYesYes
ECU ConfigurationYesYesYes
ADAS CalibrationYesYesYes
VAG Guided FunctionYesYesYes
BMW Test PlanYesYesYes
Online ProgrammingXYesYes
Offline Programming (PMI)YesYesYes
CAN FDYesYesYes
DoIPYesYesYes
J2534XXYes
Topology MappingYesYesYes

In sum:

Their hard configuration is the same.

They share the same diagnostics and service functions. They all support ECU cding, VAG guided function, BMW test plan, ADAS calibration, Topology function.

D9S cannot do built-in online programming. D9S Pro and D9 Max can do.

D9S and D9S Pro cannot do J2534 ecu programming, but the D9 MAX does.

D9 MAX comes with J2534 VCI, fits for J2534-1 and J2534-2 Standards, supports ecu reprogramming for GM, Ford, Honda, Nissan, Toyota, VW, Volvo, Subaru, Jaguar, Land Rover, Mazda , more brands coming soon.

Please Connect to PC: Prepare PC(Windows)-Download J2534 Driver APP(Check with XTOOL)-Update the Driver-Connect VCI to PC-Open the Driver-Open OEM Software-Connect to Vehicle to Start ECU Programming.

Wednesday, September 17, 2025

Xtool D5 vs D6 vs D7 vs D8

 Here is a comparison table among Xtool’s DIY series diagnostic scanner D5, D5S, D6 and D6S.



Xtool D5 vs D5S vs D6 vs D6S

D SeriesXtool D5Xtool D5SXtool D6Xtool D6S
Operating systemLinuxLinuxLinuxLinux
ProcessorDual-core 1.2GHzDual-core 1.2GHzDual-core 1.2GHzDual-core 1.2GHz
Memory128M+32GB (extend to 128GB)128M+32GB (extend to 128GB)128M+32GB (extend to 128GB)128M+32GB (extend to 128GB)
Screen size5.45 inch5.45 inch5.45 inch5.45 inch
Battery Capacity3150mAh 3.6V3150mAh 3.6V3150mAh 3.6V3150mAh 3.6V
Connection methodUSBUSBUSBUSB
Charging methodType-C cableType-C cableType-C cableType-C cable
Free updateLifetime free updateLifetime free updateLifetime free updateLifetime free update
Full system diagnostics5 systems5 systemsYesYes
Complete OBDII functionYesYesYesYes
AutoScanYesYesYesYes
Read ECU info.YesYesYesYes
Read/Clear DTCYesYesYesYes
Live DataYesYesYesYes
Read Freeze FrameYesYesYesYes
Active Test (Bidirectional control)XXXX
Special functions9+15+15+30+
IMMO ResetXXXX
ECU CodingXXXX
ECU ConfigurationXXXX
CAN FDYesYesYesYes
DoIPXXXX
Topology MappingXXXX

In sum:

The Xtool D5 and D6 series share the same hardware but differ in their software configurations.

Xtool D5 series is not full system diagnostic scanner, it supports 5 system diagnoses only. D6 series is for full system.

Special functions D5>D5S=D6>D6S. D6S has more special functions (30).

Both D5 and D6 support CAN FD protocol, but don’t support DoIP protocol.

Both scanners don’t support active test (di-directional control) function.



FYI:

Here is a table comparison among Xtool D series diagnostic tools, D5 vs D6 vs D7 vs D8 vs D9 series

Xtool D5 vs D6 vs D7 vs D8

Thursday, August 14, 2025

How to Unlock VAG SFD Gateway with Xtool?

 How to use XTOOL diagnostic tools to unlock SFD security gateway in Volkswagen and Audi vehicles? When unlocked through xtool, any diagnostic tool can be used later with the car.



Here we will show how to unlock VAG SFD with Xtool manually.



Comaptible devices: Xtool D8 series, D9 series (D9SD9S Pro), A80/H6 series, XT80, XT90 etc.

NOTE: Xtool doesn’t provide SFD unlock token. Need to obtain unlock tokens from 3rd party. (Check here to get tokens)



Procedure:
First tap Auto Scan to identify vehicle information.

Unlock VAG SFD Gateway with Xtool 1

Xtool will prompt the current model requires SFD unlocking. Hit continue.

Unlock VAG SFD Gateway with Xtool 2
How to access Xtool SFD unlock menu:

Path 1: Single system entry
Go to Full system diagnostic-select a single system

Unlock VAG SFD Gateway with Xtool 3

Unlock VAG SFD Gateway with Xtool 4
After entering this mode, the xtool will automatically detect the vehicle brand and whether the system includes SFD protection.
Hit Manual unlock to submit the unlock request.

Unlock VAG SFD Gateway with Xtool 5

The xtool system generates a data package, that’s required to obtain unlock authorization.
There are three ways to access this unlock request data:

Unlock VAG SFD Gateway with Xtool 6

Option 1:
Generate QR code.
Scan the QR code to obtain Unlock Request Data.

Unlock VAG SFD Gateway with Xtool 7

Option 2:
Share the unlock request code via email.
The system will send the request data to your email address.

Unlock VAG SFD Gateway with Xtool 8

Option 3
Tap a server link to open a webpage where you can submit the data and receive a token.

Unlock VAG SFD Gateway with Xtool 9

Unlock VAG SFD Gateway with Xtool 10
After submitting the request, you will need to retrieve the unlock token.
Manually input the token into the tool.

Xtool will automatically retrieve it from the server with one tap to complete token transfer.

Unlock VAG SFD Gateway with Xtool 11

Path 2: Auto scan path.

Hi Auto scan.
The system performs a full scan of all modules.
One completed it display which modules are protected by SFD, which ones are unlocked, and how much time remains before the unlock expires.

Unlock VAG SFD Gateway with Xtool 12

Unlock VAG SFD Gateway with Xtool 13

Unlock VAG SFD Gateway with Xtool 14



Select the module and go to the unlocking process.
For example, enter the engine control module.

Unlock VAG SFD Gateway with Xtool 15

You will see that the SFD status is currently locked.
Hit Manual Unlock.
Tap Share.

Unlock VAG SFD Gateway with Xtool 16

Tap a server link to open a webpage where you can submit the data and receive a token.

Unlock VAG SFD Gateway with Xtool 17

Input SFD unlock token.
The system will start the unlocking process.
Once successful, it will notify you and show how long the unlock will remain valid to perform real functions.

Unlock VAG SFD Gateway with Xtool 18
Once unlock the SFD, you can begin using advanced diagnostic features.

Unlock VAG SFD Gateway with Xtool 19

Monday, April 14, 2025

Xtool Program VW Passat CC 2014 ID48 All Keys Lost

 In this guide, we’ll walk through the process of creating a dealer key using the XTOOL IP900/D9/X100 PAD3 etc and KC501 programmer. This method involves reading the ID48 chip from the vehicle’s EPROM (95C320) to extract the necessary data for programming a new key.



Tools Required

  1. XTOOL IP900/D9/A80/X100 PAD3 etc (with KC501 adapter).
  2. Soldering equipment (hot air station, flux, soldering iron).
  3. EPROM reader (compatible with 95C320 chip).
  4. New ID48 transponder chip (for dealer key).
  5. Magnifying tool (for identifying chip pins).





Step 1: Locate and Remove the EPROM Chip

  1. Access the ECU: Open the vehicle’s immobilizer unit to locate the 95C320 EPROM chip.
  2. Identify Pin 1: Look for the small white dot or marking on the chip (bottom left corner). This indicates Pin 1, crucial for proper alignment.
  3. Desolder the Chip:
    • Apply flux around the chip to ease removal.
    • Use a hot air station (set to ~400°C) to gently heat the chip’s edges until it lifts off.

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 1

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 2

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 3

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 4

Step 2: Read the EPROM Data

  1. Connect the Chip: Place the desoldered chip into the EPROM adapter, ensuring Pin 1 aligns correctly.
  2. Use XTOOL KC501:
    • Navigate to Special Functions > EPROM > ST 95C320.
    • Select “Read Data” to extract the immobilizer information.
    • Save the data.

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 5

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 6

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 7

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 8

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 9

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 10

Step 3: Extract the PIN Code

  1. Open XTOOL IP900:
    • Select IMMO Reset- Volkswagen > Passat CC (2008–2017).
    • Choose “Get CS Code” and load the saved EPROM file.
    • The tool will automatically display the 4-digit PIN code (required for key programming).

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 11

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 12

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 13

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 14

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 15

Step 4: Program the New Key

  1. Prepare the Key:
    • Place a new ID48 transponder in the key programming coil (connected to the KC501).
  2. Start Programming:
    • Select “Make Dealer Key” and enter the extracted PIN code.
    • Follow on-screen prompts to complete the process.
  3. Verification:
    • The tool will confirm “Success” once the key is programmed.

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 16

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 17

Xtool Program VW Passat CC 2014 ID48 All Keys Lost 18

Final Steps

  • Reinstall the EPROM: Solder the chip back onto the ECU (if needed).
  • Test the Key:
    • Start the vehicle to ensure the new key is recognized.
    • Verify remote functions (lock/unlock).
